#2 Standard Box Track
400 lb Capacity
#2 Box Rail Track
#2 Box Rail Track
#2 Box Rail Track Dimensions
#2 Box Rail Track Dimensions
#2 Standard Box Track
This is our most versatile and popular box rail option. Use this track with any Box Track Brackets and Hangers.  For single track runs, space brackets 24" on center.  Double-track runs require brackets every 18" on center.  Our #2 box track is made of 16 gauge galvanized steel.
Available lengths: 6' 8' 10' 12' 14' 16' 18' 20' 24'
Track brackets and trolleys are sold separately
unless you purchase a package.
#2 Track Packages
Please email us or call 740-972-2275 for prices on the packages below or any other track systems and sizes you need.
We offer Sliding Packages with #2 Track, Wall Brackets and Choice of Trolley/Hanger Styles.
For approximate weight of up to 400 pounds, #2 box rail requires a track bracket mounted to the header every 2 feet with one at each end.
Lead time for #2 track packages is usually 1 week or less from paid order to ship date.
The #2 box rail kits are for single track runs only. For other applications, please contact us or call 740-972-2275.
Choose your trolley style when you purchase a package. 9-2C Wall Brackets come with our Standard #2 Box Track Packages.
Let us know if you want a price on a #2 Standard Box Track Package with another choice of brackets.
Only 6' or 8' sections can ship UPS.
Contact us for pricing on longer track or purchase splice brackets to hold sections of track together.
Please provide a phone number for residential shipping.
6' #2 Box Track Packages for ONE Door Include:
(1 pair) Trolleys/Hangers,
(4) 9-2C Wall Brackets, and
(1) 6 ft. section of #2 box rail track
This 6' rail package kit can accommodate one 3' wide door.
8' #2 Box Track Packages for ONE Door Include:
(1 pair) Trolleys/Hangers,
(5) 9-2C Wall Brackets,  and
(1) 8 ft. section of #2 box rail track
This 8' rail package kit can accommodate one 4' wide  door.
8' #2 Box Track Packages for TWO Doors Include:
(2 pair) Trolleys/Hangers,
(5) 9-2C Wall Brackets,  and
(1) 8 ft. section of #2 box rail track
This 8' rail package kit can accommodate two 2' wide  door.
12' #2 Box Track Packages for ONE Door Include:
(1 pair) Trolleys/Hangers,
(1) 9-2J Splice Bracket,
(6) 9-2C Wall Brackets, and
(2) 6 ft. sections of #2 box rail track
This 12' rail package kit can accommodate one 6' wide  door.
12' #2 Box Track Packages for TWO Doors Include:
(2 pair) Trolleys/Hangers,
(1) 9-2J Splice Bracket,
(6) 9-2C Wall Brackets, and
(2) 6 ft. sections of #2 box rail track
This 12' rail package kit can accommodate two 3' wide  doors.
14' #2 Box Track Packages for ONE Door Include:
(1 pair) Trolleys/Hangers,
(1) 9-2J Splice Bracket,
(7) 9-2C Wall Brackets,
(1) 6 ft. section of #2 box rail track, and
(1) 8 ft. section of #2 box rail track
This 14' rail package kit can accommodate one 7' wide  door.
14' #2 Box Track Packages for TWO Doors Include:
(2 pair) Trolleys/Hangers,
(1) 9-2J Splice Bracket,
(7) 9-2C Wall Brackets,
(1) 6 ft. section of #2 box rail track, and
(1) 8 ft. section of #2 box rail track
This 14' rail package kit can accommodate two 3'6" wide  doors.
16' #2 Box Track Packages for ONE Door Include:
(1 pair) Trolleys/Hangers,
(1) 9-2J Splice Bracket,
(8) 9-2C Wall Brackets, and
(2) 8 ft. sections of #2 box rail track
This 16' rail package kit can accommodate one 8' wide  door.
16' #2 Box Track Packages for TWO Doors Include:
(2 pair) Trolleys/Hangers,
(1) 9-2J Splice Bracket,
(8) 9-2C Wall Brackets, and
(2) 8 ft. sections of #2 box rail track
This 16' rail package kit can accommodate two 4' wide  doors.
18' #2 Box Track Packages for ONE Door Include:
(1 pair) Trolleys/Hangers,
(2) 9-2J Splice Bracket,
(8) 9-2C Wall Brackets, and
(3) 6 ft. sections of #2 box rail track
This 18' rail package kit can accommodate one 9' wide  door.
18' #2 Box Track Packages for TWO Doors Include:
(2 pair) Trolleys/Hangers,
(2) 9-2J Splice Bracket,
(8) 9-2C Wall Brackets, and
(3) 6 ft. sections of #2 box rail track
This 18' rail package kit can accommodate two 4'6" wide  doors.
20' #2 Box Track Packages for ONE Door Include:
(1 pair) Trolleys/Hangers,
(2) 9-2J Splice Bracket,
(9) 9-2C Wall Brackets,
(2) 6 ft. sections of #2 box rail track, and
(1) 8 ft. section of #2 box rail track
This 20' rail package kit can accommodate one 10' wide  door.
20' #2 Box Track Packages for TWO Doors Include:
(2 pair) Trolleys/Hangers ,
(2) 9-2J Splice Bracket,
(9) 9-2C Wall Brackets,
(2) 6 ft. sections of #2 box rail track, and
(1) 8 ft. section of #2 box rail track
This 20' rail package kit can accommodate two 5' wide  doors.
22' #2 Box Track Packages for ONE Door Include:
(1 pair) Trolleys/Hangers,
(2) 9-2J Splice Bracket,
(10) 9-2C Wall Brackets,
(1) 6 ft. section of #2 box rail track, and
(2) 8 ft. sections of #2 box rail track
This 22' rail package kit can accommodate one 11' wide  door.
22' #2 Box Track Packages for TWO Doors Include:
(2 pair) Trolleys/Hangers,
(2) 9-2J Splice Bracket,
(10) 9-2C Wall Brackets,
(1) 6 ft. section of #2 box rail track, and
(2) 8 ft. sections of #2 box rail track
This 22' rail package kit can accommodate two 5'-6" wide  doors.
24' #2 Box Track Packages for ONE Door Include:
(1 pair) Trolleys/Hangers,
(2) 9-2J Splice Bracket,
(11) 9-2C Wall Brackets, and
(3) 8 ft. section of #2 box rail track
This 24' rail package kit can accommodate one 12' wide  door.
24' #2 Box Track Packages for TWO Doors Include:
(2 pair) Trolleys/Hangers,
(2) 9-2J Splice Bracket,
(11) 9-2C Wall Brackets, and
(3) 8 ft. section of #2 box rail track
This 24' rail package kit can accommodate two 6' wide  doors.
Add #2 Track End Blinds (2-EB End Blinds) to your package.
#2 Track End Caps fit at the end of the track to keep it free from birds, weather and other obstructions.
End blinds/end caps work with all standard track brackets and #2 track only.
End Blinds do not stop the door.
They keep birds out of the track and give the track ends a finished look.
Add 2 end blinds to any #2 Box Track Package for $4.  Please contact us for this price.
#2 Track End Blinds (2-EB End Blinds)
#2 Track End Blinds (2-EB End Blinds)
Please check out our Sliding Door Accessories such as Door Stops, Door Pulls, Interior Latches, Stay Rollers, Bottom Guides and more!
Sliding Door Accessories
